Robertsonian translocation 14;21

45,XY,rob(14;21)(q10;q10)

Also known as: rob(14;21), translocation Down carrier

45,XY,rob(14;21)(q10;q10) is a balanced Robertsonian translocation carrier. The person is healthy, but the translocation is a familial cause of translocation Down syndrome in offspring.

Open in the interactive visualizer →

der(14)
14
21
Robertsonian translocation 14;21 (45,XY,rob(14;21)(q10;q10)) drawn by KaryoDraw, showing the involved chromosomes with their normal homolog.

What the notation means

45
total chromosome count (normal is 46)
XY
sex chromosomes: one X, one Y (usual male karyotype)
rob(14;21)(q10;q10)
a ROBERTSONIAN translocation: the long arms of chromosomes 14 and 21 are fused at the centromere into one derivative chromosome, and the two short arms are lost. They are written lowest-number-first by convention, not by which centromere is kept; whole-arm fusions like this are usually dicentric, with one centromere inactivated

KaryoDraw is a free ISCN 2024 karyotype visualizer, a StudyRare tool. It is an educational visualizer of cytogenetic nomenclature, not a diagnostic tool.
